1. HD-6 series non-flame-retardant thermal shrinkable bushing is made of excellent high polymer. When the products are shapedthey are cross linked and expanded continuously with electronic accelerator. The products are characterized by soRnessflame reatardationfast shrinkagebright and durable color,and stable performance. They are widely used in the electrical connectionelectrical end treatment and welding protection without flame-retardant requirements;the surface protection for spare parts of body-buiIding facilities and steel structrue;handrail of farming and household machinery;sutrace protection of racksand the decoration and lamps.
Softnessinsulationfast flexibility,bright luster,convenient useable to shrink when heated with oven or hot air gun.
Standard color:Transparent(Other colors are upon the cllents¡¯needs).
2. Features:
Application:-40¡æ¡«50¡æ;
Initial shrinking temperature:70¡æ;
Full shrinking temperature: 125¡æ;
¡Üaxial contraction rate of 8% shrinking ratio:2:1.
| Specification | Dimension before shrinking(mm) | Dimension after shrinking (mm) |
Standard packaging (m/disc) |
Application (mm) |
||
| Internal diameter | Wall thickness | Internal diameter | Wall thickness | |||
| ¦µ0.8 | 0.9¡À0.2 | 0.20¡À0.05 | 0.40¡À0.1 | 0.32¡À0.05 | 200 | 0.6¡«0.8 |
| ¦µ1.0 | 1.2¡À0.3 | 0.20¡À0.05 | 0.48¡À0.1 | 0.32¡À0.05 | 200 | 0.75¡«0.9 |
| ¦µ1.5 | 1.7¡À0.3 | 0.20¡À0.05 | 0.73¡À0.1 | 0.32¡À0.05 | 200 | 0.95¡«1.4 |
| ¦µ2.0 | 2.2¡À0.3 | 0.25¡À0.05 | 0.98¡À0.1 | 0.32¡À0.05 | 200 | 1.1¡«1.8 |
| ¦µ2.5 | 2.6¡À0.3 | 0.25¡À0.05 | 1.23¡À0.2 | 0.35¡À0.05 | 200 | 1.35¡«2.3 |
| ¦µ3.0 | 3.2¡À0.4 | 0.25¡À0.05 | 1.45¡À0.2 | 0.35¡À0.05 | 200 | 1.6¡«2.7 |
| ¦µ3.5 | 3.6¡À0.4 | 0.25¡À0.05 | 1.72¡À0.2 | 0.35¡À0.05 | 200 | 1.85¡«3.2 |
| ¦µ4.0 | 4.2¡À0.4 | 0.25¡À0.05 | 1.96¡À0.2 | 0.35¡À0.05 | 200 | 2.1¡«3.6 |
| ¦µ4.5 | 4.6¡À0.4 | 0.25¡À0.05 | 2.20¡À0.2 | 0.35¡À0.05 | 200 | 2.35¡«4.0 |
| ¦µ5.0 | 5.2¡À0.4 | 0.25¡À0.05 | 2.48¡À0.2 | 0.35¡À0.05 | 200 | 2.6¡«4.5 |
| ¦µ6.0 | 6.2¡À0.4 | 0.28¡À0.15 | 2.96¡À0.3 | 0.45¡À0.15 | 200 | 3.1¡«5.4 |
| ¦µ7.0 | 7.2¡À0.4 | 0.28¡À0.15 | 3.48¡À0.3 | 0.45¡À0.15 | 100 | 3.7¡«3 |
| ¦µ8.0 | 8.2¡À0.5 | 0.28¡À0.15 | 3.95¡À0.3 | 0.45¡À0.15 | 100 | 4.2¡«7.2 |
| ¦µ9.0 | 9.2¡À0.5 | 0.30¡À0.15 | 4.40¡À0.3 | 0.50¡À0.15 | 100 | 4.7¡«8.0 |
| ¦µ10 | 10.2¡À0.5 | 0.30¡À0.15 | 4.90¡À0.3 | 0.50¡À0.15 | 100 | 5.2¡«9.0 |
| ¦µ11 | 11.2¡À0.5 | 0.30¡À0.15 | 5.40¡À0.3 | 0.50¡À0.15 | 100 | 5.7¡«10 |
| ¦µ12 | 12.2¡À0.5 | 0.30¡À0.15 | 5.90¡À0.5 | 0.50¡À0.15 | 100 | 6.2¡«11 |
| ¦µ13 | 13.2¡À0.5 | 0.33¡À0.15 | 6.40¡À0.5 | 0.50¡À0.15 | 100 | 6.7¡«12 |
| ¦µ14 | 14.2¡À0.5 | 0.35¡À0.15 | 6.90¡À0.5 | 0.50¡À0.15 | 100 | 7.3¡«13 |
| ¦µ15 | 15.2¡À0.6 | 0.38¡À0.15 | 7.40¡À0.5 | 0.60¡À0.15 | 100 | 7.8¡«14 |
| ¦µ16 | 16.2¡À0.6 | 0.38¡À0.15 | 7.90¡À0.5 | 0.60¡À0.15 | 100 | 8.3¡«15 |
| ¦µ17 | 17.2¡À0.6 | 0.38¡À0.15 | 8.40¡À0.5 | 0.60¡À0.15 | 100 | 8.8¡«16 |
| ¦µ18 | 18.2¡À0.6 | 0.40¡À0.15 | 8.90¡À0.5 | 0.60¡À0.15 | 100 | 9.3¡«17 |
| ¦µ20 | 20.2¡À0.8 | 0.40¡À0.20 | 9.90¡À0.5 | 0.70¡À0.20 | 100 | 11.4¡«19 |
| ¦µ22 | 22.2¡À0.8 | 0.42¡À0.20 | 10.80¡À1.0 | 0.70¡À0.20 | 100 | 12.4¡«21 |
| ¦µ25 | 25.3¡À0.8 | 0.45¡À0.20 | 12.30¡À1.0 | 0.70¡À0.20 | 50 | 12.8¡«24 |
| ¦µ28 | 28.3¡À0.8 | 0.45¡À0.20 | 13.50¡À1.0 | 0.70¡À0.20 | 50 | 14.4¡«29 |
| ¦µ30 | 30.2¡À0.8 | 0.45¡À0.20 | 14.70¡À1.0 | 0.70¡À0.20 | 50 | 16¡«29 |
| ¦µ35 | 35.2¡À0.8 | 0.50¡À0.20 | 17.30¡À1.0 | 0.80¡À0.20 | 50 | 18¡«34 |
| ¦µ40 | 40.0¡À1.0 | 0.50¡À0.20 | 19.80¡À1.0 | 0.80¡À0.20 | 50 | 21¡«39 |
| ¦µ50 | 50.0¡À1.0 | 0.50¡À0.20 | 24.80¡À1.0 | 0.80¡À0.20 | 50 | 26¡«49 |
