Insulated Blade Terminals — DBV Series

Vinyl-insulated blade crimp terminals for clean push-in connections to clamp or slot-type terminals (22–10 AWG / 0.5–6 mm²).
Color sections & typical currents from the catalog: Red 19 A, Blue 19 A, Yellow 48 A.
Flat blade prevents strand splay and speeds service; consistent barrels for reliable crimps.

Overview

The DBV Series insulated blade terminals provide a flat, solid contact for clamp and slot-type terminal blocks.
Covering 22–10 AWG (0.5–6 mm²), these insulated blade terminals use color-coded vinyl sleeves for fast pick and strain relief.
Typical currents by section (per catalog): Red 19 A, Blue 19 A, Yellow 48 A.

Flat blade tongue inserts cleanly and resists strand splay.
Vinyl insulation improves grip and provides dielectric protection.
Crimp barrels work with standard ratchet tools for repeatable terminations.
Ideal wherever insulated blade terminals must slide into spring/screw clamps or relay bases.

Specifications (Complete Series)

Model	B (mm)	L (mm)	F (mm)	H (mm)	DØ (mm)	Color / Section
0.5–1.5 mm² (22–16 AWG) — Imax 19 A
DBV1.25-10	2.3	20.0	10.0	10.0	4.3	Red
DBV1.25-11	3.0	21.0	11.0	10.0	4.3	Red
DBV1.25-14	3.0	24.0	14.0	10.0	4.3	Red
DBV1.25-18	2.3	28.0	18.0	10.0	4.3	Red
1.5–2.5 mm² (16–14 AWG) — Imax 19 A
DBV2-9	2.8	19.0	9.0	10.0	4.3	Blue
DBV2-18	2.3	28.0	18.0	10.0	4.3	Blue
4–6 mm² (12–10 AWG) — Imax 48 A
DBV5.5-10	2.8	22.5	10.0	13.0	5.6	Yellow

Dimensions transcribed from the catalog page provided. Verify the exact model and torque guidance for your application.

Dimension

Applications

Clamp/spring terminal blocks, relay bases, control panels
Retrofits where flat blades are preferred over pins or rings
Use with heat-shrink tube for extra strain relief

Ordering Guide

Select conductor size, then match blade length (F) and width (B) to your terminal.
WILLELE supplies insulated blade terminals in red/blue/yellow sections covering 22–10 AWG with typical currents up to 48 A.
