K-Type Circle Cable Clips WLR — Round Cable Clips with Nails (PE White)
K type circle cable clips in elastic PE with pre-fitted hardened nails.
Quick nail-in install; protects cable jackets; neat routing on walls and wood.
Inner sizes 4–32 mm with matched nail lengths.
Overview
K type circle cable clips are U-shaped, round cable clips with nails. The white PE saddle offers high elasticity and impact resistance; the carbon-steel nail is pre-mounted for one-hit installation that saves time and labor. This K-profile leaves extra clearance at the crown for jacket protection and tidy routing.
Product Features
- Elastic PE saddle absorbs impact and holds round cables securely.
- Hardened, zinc-plated nails withstand repeated driving and 90° bending.
- Fast nail-in design; consistent depth and neat finish on walls and wood.
- Sizes 4–32 mm to cover data, coax, control cables and small conduits.
Technical Information
- Material: PE (white) injection molded saddle; carbon-steel nail.
- Recommended base: wood, plaster, masonry (pilot hole as needed).
- Finish: white standard; black/UV versions available on request.
Dimension
Dimensions shown as overall height H, inner height T, inner width W, and matched nail size.
Specifications
| Item No. | H (mm) | T (mm) | W (mm) | Nail Size (mm) |
|---|---|---|---|---|
| WLR-K-4mm | 6.5 | 4.5 | 4 | 2.5×18 |
| WLR-K-5mm | 7.5 | 5.5 | 5 | 2.5×18 |
| WLR-K-6mm | 9.5 | 7.3 | 6 | 2.5×18 |
| WLR-K-7mm | 11.0 | 7.8 | 7 | 2.5×22 |
| WLR-K-8mm | 11.5 | 8.5 | 8 | 2.5×22 |
| WLR-K-9mm | 12.5 | 9.5 | 9 | 2.5×22 |
| WLR-K-10mm | 13.8 | 10.5 | 10 | 2.5×26 |
| WLR-K-11mm | 14.8 | 11.5 | 11 | 2.5×26 |
| WLR-K-12mm | 16.0 | 12.5 | 12 | 2.5×26 |
| WLR-K-14mm | 18.0 | 14.5 | 14 | 3.0×35 |
| WLR-K-16mm | 25.5 | 16.5 | 16 | 3.2×38 |
| WLR-K-18mm | 25.5 | 18.5 | 18 | 3.2×38 |
| WLR-K-20mm | 25.0 | 20.8 | 20 | 3.2×38 |
| WLR-K-22mm | 27.2 | 22.5 | 22 | 3.2×42 |
| WLR-K-25mm | 30.2 | 25.5 | 25 | 3.2×47 |
| WLR-K-32mm | 38.0 | 32.5 | 32 | 3.5×56 |
Applications
- Residential/office routing of LAN, coax and speaker lines with k type circle cable clips.
- Retail display wiring using k type round cable clips for neat edges.
- Light PVC conduits on wooden frames with fast nail-in installation.
