Willele WLE Series Push-in Wire Connectors
Tool-free push-in connection for fast, reliable wiring in lighting, appliances, and junction boxes.
Rated voltage 400 V / 600 V; rated current 24 A / 32 A / 41 A (per model).
Insulation: PA; conductor insert: copper/brass for low contact resistance.
Strip length: typically 9–12 mm (some models 12–13 mm), with clear circuit patterns and sizes.
Overview
The Willele WLE push in wire connector are tool-free push-in wire connectors for fast, gas-tight
terminations in lighting, appliances, junction boxes, and distribution enclosures. A flame-retardant
PA housing and copper/brass insert ensure stable conductivity and long service life.
The family covers 400 V / 600 V applications with model options rated
24 A / 32 A / 41 A. Typical strip length is 9–12 mm
(some models 12–13 mm).
Key Features
- Push-in spring technology for quick, repeatable, and tool-free wiring.
- PA insulating body with copper/brass conductor insert for low contact resistance.
- Clear circuit patterns (one-in/one-out, one-in/multi-out) to simplify installation.
- Available in half-transparent or transparent bodies for easy visual inspection.
Materials & Ratings
- Insulation: PA (flame-retardant)
- Insert: Copper / Brass
- Rated voltage: 400 V, 600 V
- Rated current: 24 A / 32 A / 41 A (model-dependent)
- Conductor strip length: 9–12 mm (some types 12–13 mm)
Model Line-up
| Model | Body | Typical circuit | Typical rating | Notes |
|---|---|---|---|---|
| WLE-102A / WLE-102C | A = half-transparent, C = transparent | One-in / one-out | Up to 400/600 V, 24–41 A (by model) | C-types are custom versions |
| WLE-104A / WLE-104C | A = half-transparent, C = transparent | One-in / three-out | Up to 400/600 V, 24–41 A (by model) | C-types are custom versions |
| WLE-106A / WLE-106C | A = half-transparent, C = transparent | One-in / five-out | Up to 400/600 V, 24–41 A (by model) | C-types are custom versions |
| WLE-108A / WLE-108C | A = half-transparent, C = transparent | One-in / seven-out | Up to 400/600 V, 24–41 A (by model) | C-types are custom versions |
| WLE-602A | Half-transparent | One-in / one-out (large size) | Up to 400/600 V, model-rated current | — |
| WLE-604A | Half-transparent | One-in / two-out (large size) | Up to 400/600 V, model-rated current | — |
| WLE-606A | Half-transparent | One-in / five-out (large size) | Up to 400/600 V, model-rated current | — |
| WLE-103D(A) / WLE-103D(C) | A = half-transparent, C = transparent | One-in / three-out (distribution) | Up to 400/600 V, model-rated current | C-type is custom |
| WLE-104D(A) | Half-transparent | One-in / four-out (distribution) | Up to 400/600 V, model-rated current | — |
Dimensions & Circuit Diagrams
Note: The WLE renaming only changes the model prefix. All electrical ratings, wire ranges,
dimensions, and circuit patterns remain the same as your original datasheet.
