Flat Palm Bimetal Cable Lugs — DTL-2F Series

DTL-2F flat-palm bimetal cable lugs for aluminium cable to copper busbar/stud.
Cu palm + Al barrel friction-welded for low resistance & anti-galvanic corrosion.
Flat palm profile for compact installs and large contact area.
Complete Φ / D / d / L / L1 size matrix from 16–630 for quick die/bolt selection.

Overview — DTL-2F flat palm bimetal lug

The DTL-2F Series are flat palm bimetal lug (Cu–Al) designed to connect
aluminium conductors to copper busbars or studs. The aluminium barrel (L3) is
friction-welded to a copper palm (T2), ensuring excellent electrical performance, strong mechanical integrity and
resistance to galvanic corrosion. The flat palm profile provides a larger contact area with a low
overall height—ideal for compact panels, MCCs and switchgear.

Type: Flat palm bimetal cable lug (DTL-2F) |
Materials: Barrel—Al (L3) / Palm—Cu (T2), friction welded |
Use: Aluminium cable to copper termination |
Dimensions: Φ (stud hole), D (barrel OD), d (barrel ID), L (overall), L1 (palm length)

Technical Data — Dimensions (mm)

Type	Φ	D	d	L	L1
DTL-2-F-16	8	16	5.5	81	39
DTL-2-F-25	8	16	6.5	81	39
DTL-2-F-35	8	16	8	89	39
DTL-2-F-50	10	20	9	90	47
DTL-2-F-70	10	23	11	90	47
DTL-2-F-95	10	25	12.5	99	50
DTL-2-F-120	11	25	13.5	111	60
DTL-2-F-150	11	32	15.5	111	60
DTL-2-F-185	13	32	17.5	122	63
DTL-2-F-240	13	32	19.5	122	63
DTL-2-F-300	13	40	21	133	74
DTL-2-F-400	13	40	29	156	85
DTL-2-F-500	13	47	29	156	85
DTL-2-F-630	10	47	32.5	183	97

Installation Notes

Prepare aluminium strands (brush & apply oxide-inhibiting compound) before insertion.
Crimp along the barrel with the specified hex/compression dies to rated pull-out.
Mount to the copper bus/stud with the specified Φ hole size and the correct torque.
Seal the joint (heat-shrink/insulation) to meet the site’s environmental class.
